The format of the created CNC program depends on the machine, which can be specified for any material in the Woodwork for Inventor add-on. Once the desired layout results are achieved, a single command is used to generate CNC programs for each individual workpiece sheet. Cutting characteristics are thereby programmed for all parts of the product. If necessary, parts can be deleted, copied or moved to another sheet. The user can edit the layout schemes interactively, change the position and direction of parts on the sheet. All parts are arranged on workpiece sheets suitable for the material of the parts. Here, the user will be provided with a preliminary layout of CNC technologies (parts) onto workpiece sheets. Then, the CNC technologies can be automatically selected and transferred to the cutting scheme design environment. The technologies created will take into account the edge banding and pattern direction of the part. User can open the designed product and automatically create CNC technologies for each individual part.
Woodwork for Inventor CAM module has an additional feature which allows creating CNC programs used to cut out parts from a single workpiece sheet.
